Chemical composition of 6063 conductive aluminum tube
Si: 0.20-0.6
Fe: 0.35
Cu: 0.10
Mn: 0.10
Mg: 0.45-0.9
Cr: 0.10
Zn: 0.10
Ti: 0.10
Al: margin
Other: Single: 0.05 Total: 0.15
Technical requirements of 6063 aluminum tube:
1) The nozzle is flat and perpendicular to the axis.
2) The length deviation of the busbar is positive error: +15~+25mm
3) The pipe busbar is allowed to have straightening spiral marks that do not affect the outer diameter size, and its depth does not exceed 0.5m
4) Bending degree of pipe busbar: m/L<2.0mm
5) The distance between the pipe mother and its matching liner is not more than 0.5mm and can ensure the installation requirements.
6) The surface of the busbar is smooth and smooth, without cracks, wrinkles, inclusions, deformation and distortion.
